Bộ phát Wifi Cisco Catalyst C9105AXW-S Access Point
Bộ phát Wifi Cisco Catalyst C9105AXW-S Access Point
| Item | Specification | |||||||||
| Part numbers | Cisco Catalyst 9105AX Access Point: Indoor environments, with internal antennas ● C9105AXI-x: Cisco Catalyst 9105 Series Cisco Catalyst 9105AX Access Point: Wall Plate, with internal antennas ● Bộ phát Wifi Cisco Catalyst C9105AXW-S Access Point : Cisco Catalyst 9105 Series Cisco Catalyst 9105AX Teleworker Access Point: Indoor environments, with internal antennas ● C9105AXIT-x: Cisco Catalyst 9105 Series (Shipped along with Infrastructure kit - Power Injector and Ethernet Cables) Cisco Catalyst 9105AX Teleworker Access Point: Wall Plate, with internal antennas ● C9105AXWT-x: Cisco Catalyst 9105 Series (Shipped along with Wall Plate kit - Cradle and Ethernet Cables) Cisco Catalyst 9105AX Access Point: Indoor environments, with internal antennas, with embedded wireless controller ● C9105AXI-EWC-x: Cisco Catalyst 9105 Series Regulatory domains: (x = regulatory domain) Customers are responsible for verifying approval for use in their individual countries. To verify approval and to identify the regulatory domain that corresponds to a particular country, Not all regulatory domains have been approved. As they are approved, the part numbers will be available on the Global Price List and/or regional price lists. Cisco Wireless LAN Services | |||||||||
| Accessories | ● Mounting bracket: AIR-AP-BRACKET-W4= (available as spare) ● Spacer kit: C9105AXW-KIT (sold separately) | |||||||||
| Software | Catalyst 9105 AXI ● Cisco Unified Wireless Network Software Release 8.10.MR3 or later ● Cisco IOS XE Software Release 17.3.1, or later Catalyst 9105AXW ● Cisco Unified Wireless Network Software Release 8.10MR3 or later ● Cisco IOS XE Software Release 17.3.1 or later | |||||||||
| Supported wireless LAN controllers | ● Cisco Catalyst 9800 Series Wireless Controllers ● Cisco 3504, 5520, and 8540 Wireless Controllers and Cisco Virtual Wireless Controller | |||||||||
| 802.11n version 2.0 (and related) capabilities | ● 2x2 MIMO with two spatial streams ● Maximal Ratio Combining (MRC) ● 802.11n and 802.11a/g ● 20- and 40-MHz channels ● PHY data rates up to 444.4 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz) ● Packet aggregation: Aggregate MAC Protocol Data Unit (A-MPDU) (transmit and receive), Aggregate MAC Service Data Unit (A-MSDU) (transmit and receive) ● 802.11 Dynamic Frequency Selection (DFS) ● Cyclic Shift Diversity (CSD) support | |||||||||
| 802.11ac | ● 2x2 downlink MU-MIMO with two spatial streams ● MRC ● 802.11ac beamforming ● 20-, 40-, 80- MHz channels ● PHY data rates up to 866.7 Mbps (80 MHz with 5GHz) ● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive) ● 802.11 DFS ● CSD support ● WPA3 support | |||||||||
| 802.11ax | ● 2x2 uplink/downlink MU-MIMO with two spatial streams ● Uplink/downlink OFDMA ● TWT ● BSS coloring ● MRC ● 802.11ax beamforming ● 20-, 40-, 80- channels ● PHY data rates up to 1.488 Gbps (80 MHz with 5 GHz and 20 MHz with 2.4 GHz) ● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive) ● 802.11 DFS ● CSD support ● WPA3 support | |||||||||
| Integrated antenna | Cisco Catalyst C9105AXW-S ● 2.4 GHz: Peak gain 3 dBi, internal antenna ● 5 GHz: Peak gain 5 dBi, internal antenna Catalyst 9105AXI ● 2.4 GHz: Peak gain 4 dBi, internal antenna, omnidirectional in azimuth ● 5 GHz: Peak gain 5 dBi, internal antenna, omnidirectional in azimuth | |||||||||
| Interfaces | Cisco Catalyst C9105AXW-S ● 1x 100/1000/2500 Base-T (Ethernet) Uplink Interface ● 3x 10/100/1000 Base-T (Ethernet) Downlink Interface (LAN1,LAN2 and LAN3, LAN1 supports 10.5W PSE Power Budget) ● Management console port (RJ-45) ● USB 2.0 at 4.5W ● Passthru Port Catalyst 9105AXI ● 1x 10/100/1000 Base-T (Ethernet) Uplink Interface ● Management console port (RJ-45) | |||||||||
| Indicators | ● Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors | |||||||||
| Dimensions | ● Access point (without mounting brackets): ◦ C9105AXW: 3.54 x 6.3 x 1.3 in. (90 x 160 x 32.66 mm) ◦ C9105AXI: 5.9 x 5.9 x 1.18 in. (150 x 150 x 30 mm) | |||||||||
| Weight | Cisco Catalyst C9105AXW-S ● 0.8 lb. (373.2g) Cisco Catalyst 9105AXI ● 0.7 lb. (329.5g) | |||||||||
| Input power requirements | ● 802.3at Power over Ethernet Plus (PoE+), Cisco Universal PoE (Cisco UPOE) ● Cisco power injector, AIR-PWRINJ6= ● 802.3af PoE ● Cisco power injector, AIR-PWRINJ5= ( Note: This injector supports only 802.3af) | |||||||||
| Catalyst 9105AXI | ||||||||||
| PoE power | 2.4-GHz radio | 5-GHz radio | Link speed | |||||||
| 802.3af (PoE) | 2x2 | 2x2 | 1G | |||||||
| Catalyst 9105AXW | ||||||||||
| PoE power | 2.4-GHz radio | 5-GHz radio | Link speed | USB | LAN1 PSE | |||||
| 802.3af (PoE) | 2x2 | 2x2 | 2.5G mGig | Disabled | Disabled | |||||
| 802.3at (PoE+) | 2x2 | 2x2 | 2.5G mGig | Either USB or LAN1 PSE enabled. | ||||||
