Bộ phát Wifi Cisco Catalyst C9115AXE-EWC-S Access Point
Bộ phát Wifi Cisco Catalyst C9115AXE-EWC-S Access Point
| Item | Specification | |||||||||
| Part numbers Bộ phát Wifi Cisco Catalyst C9115AXE-EWC-S Access Point | Cisco Catalyst 9115AXI Access Point: Indoor environments, with internal antennas ● C9115AXI-x: Cisco Catalyst 9115 Series Cisco Catalyst 9115AXE Access Point: Indoor, challenging environments, with external antennas ● C9115AXE-x: Cisco Catalyst 9115 Series Cisco Catalyst 9115AXI Access Point: Indoor environments, with internal antennas, with embedded wireless controller ● C9115AXI-EWC-x: Cisco Catalyst 9115 Series Cisco Catalyst 9115AXE Access Point: Indoor, challenging environments, with external antennas, with embedded wireless controller ● Cisco Catalyst C9115AXE-EWC-S Access Point: Cisco Catalyst 9115 Series Regulatory domains: (x = regulatory domain) Customers are responsible for verifying approval for use in their individual countries. To verify approval and to identify the regulatory domain that corresponds to a particular country, visit
Not all regulatory domains have been approved. As they are approved, the part numbers will be available on the Global Price List. Cisco Wireless LAN Services | |||||||||
| Software | ● Cisco Unified Wireless Network Software Release 8.9 or later ● Cisco IOS XE Software Release 16.11 or later | |||||||||
| Supported wireless LAN controllers | ● Cisco Catalyst 9800 Series Wireless Controllers ● Cisco 3500, 5520, and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller | |||||||||
| 802.11n version 2.0 (and related) capabilities | ● 4x4 MIMO with four spatial streams ● Maximal Ratio Combining (MRC) ● 802.11n and 802.11a/g beamforming ● 20- and 40-MHz channels ● PHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz) ● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive) ● 802.11 Dynamic Frequency Selection (DFS) ● Cyclic Shift Diversity (CSD) support | |||||||||
| 802.11ac | ● 4x4 downlink MU-MIMO with four spatial streams ● MRC ● 802.11ac beamforming ● 20-, 40-, 80-, and 160-MHz channels ● PHY data rates up to 3.47 Gbps (160 MHz with 5 GHz) ● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive) ● 802.11 DFS ● CSD support | |||||||||
| 802.11ax | ● 4x4 downlink MU-MIMO with four spatial streams ● Uplink/downlink OFDMA ● TWT ● BSS coloring ● MRC ● 802.11ax beamforming ● 20-, 40-, 80-, and 160-MHz channels ● PHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz) ● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive) ● 802.11 DFS ● CSD support | |||||||||
| Integrated antenna | ● 2.4 GHz, peak gain 3 dBi, internal antenna, omnidirectional in azimuth ● 5 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth | |||||||||
| External antenna (sold separately) | ● Cisco Catalyst 9115E Cisco Catalyst C9115AXE-EWC-S Access Point Access Points are certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz) ● Cisco offers the industry's broadest selection of delivering optimal coverage for a variety of deployment scenarios ● For more details, | |||||||||
| Interfaces | ● 1x 100, 1000, 2500 Multigigabit Ethernet (RJ-45) – IEEE 802.3bz ● Management console port (RJ-45) ● USB 2.0 | |||||||||
| Indicators | ● Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors | |||||||||
